Compact 4U rackmount chassis with 300 mm depth, three 3.5-inch drive positions, seven full-height slots, two 6025 fans, ATX PSU support, and front USB 2.0. Designed for enterprise IT, integrators, OEM/ODM projects, and bulk sourcing.
ISC RC4U300FW M is a compact 4U rackmount chassis for enterprise IT, storage, edge, monitoring, and integration projects.
Product Category:
4U rackmount server chassis enclosure.
Key Configuration:
482 x 300 x 178 mm, up to three 3.5-inch drives or 2.5-inch adapters, seven full-height slots, two 6025 fans, front USB 2.0, and ATX PSU support.
Compatibility:
Confirm motherboard, GPU, PSU, backplane, rail, and drive fit before ordering.
Applications:
Data centers, private cloud, research, industrial control, and managed services.
Procurement Value:
OEM/ODM design, prototyping, bulk sourcing, and distributor support simplify project procurement.
| Model | ISC-RC4U300FW-M |
|---|---|
| Dimensions(mm) | 482(W)*300(D)*178mm(H) |
| Main Board | 12"*9.6"(305*245MM) |
| Hard Disk | Three 3.5-inch Hard Disk or 2.5" HDD adapter |
| CD-ROM | No |
| Power | ATX PSU support |
| Fan | 2*6025 fan include |
| Expansion Slot | Seven Full High and Straight Slot |
| Panel Setting | Two USB2.0; One Power Switch with indicator; One reset |
| Case Material | SGCC |
| Material Thickness | 1.0MM |
| Packaging size | 54*43*27CM（0.062CBM） |
| Gross weight | 6.4KG |
| N.W | 5.2KGS |
