ISC-RC2U390L1-M is a 2U rackmount server chassis supporting up to four 3.5-inch drives, 9.6 x 9.6-inch motherboards, two 8025 fans, and four half-height slots. Built for integrators, OEM projects, distribution, and bulk procurement.
Built from 1.2 mm SGCC steel with an aluminum panel, the ISC-RC2U390L1-M is a compact 2U rackmount chassis for server and storage deployment. It supports up to four 3.5-inch drives, two 8025 fans, front USB 2.0, power and reset controls, and status indicators for practical operation in data centers, enterprise IT, edge, and research racks.
Designed for 9.6 x 9.6-inch motherboards, it offers four half-height expansion slots with an optional riser card. The chassis suits system integrators, OEM customers, distributors, and project buyers seeking configurable infrastructure. PSU format, backplane, hot-swap capability, rails, and accessories should be confirmed before ordering. iSTONECASE supports OEM/ODM development and bulk sourcing.
| Model | ISC-RC2U390L1-M |
|---|---|
| Dimensions(mm) | 482(W)*390(D)* 89 mm(H) |
| Main Board | 9.6"*9.6"(245*245MM) |
| Hard Disk | Four 3.5-inch Hard Disks |
| CD-ROM | One 5.25-inch CD-ROM |
| Power | Ordinary Desk-type PC Power Supply ATX PSU |
| Fan | Two 8025 Fans |
| Expansion Slot | Four Half High and Straight Slots (Riser Card is needed/Optional) |
| Panel Setting | Two USB2.0; One Power Switch; One Restart Switch; One Power Indicator; One HD Indicator |
| Case Material | SGCC and Aluminum panel |
| Material Thickness | 1.2MM |
| Packaging size | 55*52.5*17(0.049CBM) |
| Gross weight | 6.421KG |
| N.W | 4.812KG |
