ISC RC4U610DW-T is a 4U SGCC rackmount chassis with 2 x 3.5-inch, 1 x 2.5-inch and 2 x 5.25-inch bays, 7 full-height expansion slots and ATX PSU support. Designed for industrial, IoT, surveillance and enterprise system integration.
Product Overview: ISC RC4U610DW-T is a 4U SGCC rackmount chassis for industrial and enterprise system builds.
Product Category: 4U rackmount case for integration and project sourcing.
Key Configuration: 2 x 3.5-inch, 1 x 2.5-inch and 2 x 5.25-inch bays with 7 full-height PCI/PCIe slots.
Compatibility: Designed for ATX power supplies; motherboard, cooling, rails and other parts depend on configuration.
Applications: Industrial control, automation, IoT, surveillance, enterprise IT and data centers.
Procurement Value: OEM/ODM customization, prototyping, bulk sourcing and distributor support for integrators and project buyers.
| Model | ISC-RC4U610DW-T |
|---|---|
| Case size | 450(L)*427(W)*177(H)mm |
| Main material | Magang, environmentally friendly 1.2mm SPCC and fingerprint-resistant SGCC |
| Surface treatment | Internal parts are not sprayed, and the rest are all sprayed with computer white |
| HDD slot | 2 built-in 3.5" HDD, 1 2.5" SSD |
| CD-ROM slot | 2 5.25" optical drive bays, 1 3.5" floppy drive bay |
| Fan slot | 1 12025S fan |
| Applicable motherboard | Standard motherboards of 12"*9.6" and below |
| I/O expansion | 7 full-height PCI/PCIE expansion slots, vertically inserted |
| External interface | 2* USB 2.0 |
| System control | Power LED*1, Reset*1, Power SW*1, HDD LED*1 |
| Applicable power supply | Standard ATX power supply |
| Internal accessories | Power supply bracket, screw package |
| Safety standards | GB/T 13914-2002 |
| Packing method | Head and bottom box + outer box |
| Packing size | 580*530*260㎜ |
| Applicable fields | Industrial control, mechanical automation, intelligent transportation, Internet of Things, security monitoring and other fields |
