ISC RC4U510HW T is a 4U SGCC steel rackmount chassis with eight 3.5-inch HDD bays, two 5.25-inch bays and seven full-height PCI/PCIe slots. It supports 12 × 9.6-inch and smaller boards plus a PS2 PSU for industrial integration, OEM/ODM and bulk sourcing.
ISC RC4U510HW T is a 4U SGCC steel rackmount chassis with eight 3.5-inch HDD bays, two 5.25-inch bays and seven full-height PCI/PCIe slots. It supports 12 × 9.6-inch and smaller boards plus a PS2 PSU for industrial integration, OEM/ODM and bulk sourcing.
Product Description:
Product Overview: ISC RC4U510HW T is a 4U rackmount chassis for industrial computing, storage and IT integration.
Product Category: SGCC steel rackmount enclosure; no hot-swap backplane is specified.
Key Configuration: Eight 3.5-inch HDD bays, one 3.5-inch FDD/HDD bay, two 5.25-inch bays, seven full-height PCI/PCIe slots and front USB support.
Compatibility: Supports 12 × 9.6-inch and smaller motherboards, standard PS2 PSU and stated fan positions.
Applications: Automation, IoT, transportation, security monitoring and storage workloads.
Procurement Value: For system integrators, OEM/ODM buyers, distributors and bulk projects; confirm rails, installed fans, cables and accessories before ordering.
| Model | ISC-RC4U510HW-T |
|---|---|
| Dimensions (mm) | Depth 450mm × Width 427mm × Height 177mm, standard rack-mounted industrial chassis |
| Material | Environmentally friendly, fingerprint-resistant 1.2mm/SGCC |
| HDD Slot | 8 3.5" hard drive bays |
| FDD Slot | 1 3.5" floppy drive bay, compatible with 3.5" hard drives |
| CD-ROM Slot | 2 5.25" optical drive bays |
| Power Supply | Standard PS2 power supply |
| Fan Slot | 1 12025 fan on the front panel, 2 8025 fans on the rear window |
| Expansion Space | 7 PCI/PCIE full-height expansion slots |
| USB Interface | Supports 2 front USB ports |
| Suitable for motherboard | Supports motherboards of 12"×9.6" and below |
| Application area | Widely used in industrial control, intelligent transportation, mechanical automation, Internet of Things, security monitoring and other fields |
