ISC NS8S-T compact 8-bay NAS chassis with hot-swappable 3.5-inch drive support, selected 2.5-inch SSD compatibility, Micro-ATX support and four half-height expansion slots for storage integration, OEM/ODM and bulk sourcing.
The ISC NS8S-T is a compact 8-bay NAS chassis designed for scalable business storage integration.
Product Category:
NAS case and storage enclosure for enterprise IT, private cloud, multimedia, backup and data management.
Key Configuration:
Eight hot-swap bays, two 4-bay 6Gb SATA backplanes, four half-height PCI/PCIe slots and three specified cooling fans.
Compatibility:
Designed for Micro-ATX builds; PSU, drives and other components depend on configuration.
Applications:
Suitable for offices, SMEs, system integrators, managed services and data center storage projects.
Procurement Value:
Supports OEM/ODM development, prototyping, bulk sourcing and distributor cooperation.
| Model | ISC-NS8S-T |
|---|---|
| Chassis size (mm) | 305(W)*310(D)*221(H) (including 11mm foot pad height) |
| Main material | High-quality environmentally friendly fingerprint-resistant galvanized steel sheet, imported from Germany Covestro (Bayer) PC+ABS |
| Surface treatment | The outer surface is black, the inner steel plate is natural color |
| PCI expansion | 4 half-height PCI/PCIE expansion slots |
| HDD bit | 8 hot-swap 3.5" HDDs, compatible with 2.5" SSDs, support hot-swap |
| Hard disk backplane | Two 4-bay 6Gb SATA hard disk backplanes |
| Fan position | 2 9025S fans and 1 6025S fan |
| Applicable motherboard | Micro-ATX (9.6*9.6) and below motherboards |
| USB interface | Front 2 USB3.0 |
| System control | 1*POWER SW, 1*POWER LED, 1*RESET, 1*HDD LED |
| Applicable power supply | Standard 1U power supply, compatible with FLEX small 1U power supply |
| Internal accessories | Power bracket, screw bag |
| Packing | Front and rear pearl cotton + beer box with handle |
| Packing size(mm) | 420*415*325 |
| Applicable fields | Home storage, office audio and video, cloud storage and other fields |
| Net weight/gross weight | 5.5KG/6.5KG |
