The ISC NS8SP-T is an 8-bay hot-swap NAS chassis for MicroATX builds, with four half-height PCI/PCIe slots and multi-fan cooling. Designed for private cloud, office storage and integration projects, with OEM/ODM and volume procurement support.
The ISC NS8SP-T is an 8-bay hot-swap NAS chassis for MicroATX builds, with four half-height PCI/PCIe slots and multi-fan cooling. Designed for private cloud, office storage and integration projects, with OEM/ODM and volume procurement support.
Product Description:
Product Overview: ISC NS8SP-T is an 8-bay NAS chassis for storage system integration, not a complete server.
Product Category: Desktop NAS case for private cloud, office storage and enterprise IT.
Key Configuration: Eight hot-swap bays, four half-height PCI/PCIe slots and three-fan cooling in galvanized steel.
Compatibility: Supports MicroATX motherboards plus selected 3.5-inch HDD and 2.5-inch SSD configurations. Confirm PSU, backplane and storage interface before ordering.
Applications: Backup, file sharing, media storage and managed services.
Procurement Value: Suitable for integrators, OEM/ODM projects, prototypes, bulk sourcing and distributor programs.
| Model | ISC-NS8SP-T |
|---|---|
| Chassis size (mm) | 305(W)*310(D)*221(H) (including 11mm foot pad height) |
| Main material | High-quality environmentally friendly fingerprint-resistant galvanized steel sheet, imported from Germany Covestro (Bayer) PC+ABS |
| Surface treatment | The outer surface is black, the inner steel plate is natural color |
| PCI expansion | 4 half-height PCI/PCIE expansion slots |
| HDD bit | 8 hot-swap 3.5" HDDs, compatible with 2.5" SSDs, support hot-swap |
| Hard disk backplane | Two 4-bay 6Gb SATA hard disk backplanes |
| Fan position | 2 9025S fans and 1 6025S fan |
| Applicable motherboard | Micro-ATX (9.6*9.6) and below motherboards |
| USB interface | Front 2 USB3.0 |
| System control | 1*POWER SW, 1*POWER LED, 1*RESET, 1*HDD LED |
| Applicable power supply | Standard 1U power supply, compatible with FLEX small 1U power supply |
| Internal accessories | Power bracket, screw bag |
| Packing | Front and rear pearl cotton + beer box with handle |
| Packing size(mm) | 420*415*325 |
| Applicable fields | Home storage, office audio and video, cloud storage and other fields |
| Net weight/gross weight | 5.5KG/6.5KG |
